Sewing Needle Detector
- The Enntech ST-6000FZ detector needle machine adopts the most advanced magnetic detecting technology, use the latest computer control system, through sampling system to filter jamming signal, make the machine work more stable.
- The machine adopts magnetic circuit symmetry detection structure, reduce the magnetic radiation. In line with the green environmental protection concept, magnetic circuit in detection channel get closed-loop, improve the detection precision and the ability to resist strong magnetic interference, reduce misjudgment rate, to adapt to the harsh working environment.
- Detecting Mode: magnetic induction mode
- Detecting Capacity: iron ball Ф0.8mm
- Sensitivity Set: stepless
- Detecting Width: 600mm
- Detecting Height: 100mm
- Alarm mode: beep
- Conveyer Belt Speed: 30m/min
- Power Supply: Single-phase 220V,50Hz
- Power: 110W
- Model: HD-380E
- Detector port width: 380mm
- Detector port height: 140mm
- Detectability: 1.2 mm
- Conveyor speed: 40 m/min
- Power supply: 220V / 50Hz
- Power: 90W
- Machine dimensions: 1130(L) x 1090(H) x 750(W)mm
- Weight: 180kg
- Made in China
- Detecting Mode: electro-magnetic induction
- Detecting Ability: Fe Φ3.5mm
- Detecting Adjustment: Step-less adjustment
- Detecting Width: 700mm (Standard Type)
- Detecting Height: 380mm
- Alarm Mode: Beep
- Belt Speed: (approx.) 30m/min
- Power Supply: Single-phase 220V, 50HZ
- Rated Output: (approx.) 260W
- Dimension: 1700(L)×1150(W)×1250(H)mm
- Weight: (approx.) 280kg
The Enntech ST-30C hand held needle detector is suitable for detecting all knitwear, clothing, shoes, socks and bed sheets, etc. and quickly find out the exact location of a broken needle or piece of metal that won't reach the consumer.
- Detecting Mode: Electro-magnetic induction
- Detecting Ability: Fe Φ0.8mm
- Detecting Adjustment: Step-less adjustment
- Detecting Width: 600mm (Standard Type)
- Detecting Height: 100mm
- Alarm Mode: Beep
- Belt Speed: (approx.) 30m/min
- Power Supply: Single-phase 220V, 50HZ
- Rated Output: (approx.) 165W
- Dimension: 2300(L)×1180(W)×950(H)mm
- Weight: (approx.) 360kg
- Detecting Mode: Electro-magnetic induction
- Detecting Ability: Fe Φ1.20mm
- Sensitivity Adjustment: Step-less adjustment
- Detecting Width: 380mm (Standard Type)
- Detecting Height: 160mm
- Alarm Mode: Beep and Lamp
- Belt Speed: (approx.) 30m/min
- Power Supply: Single-phase 220V, 50HZ
- Power Supply: (approx.) 90W
- Dimension: 1200(L)×690(W)×800(H)mm
- Detecting Mode: electro-magnetic induction
- Detecting Ability: Fe Φ1.20mm
- Detecting Adjustment: Step-less adjustment
- Detecting Width: 1200mm (Standard Type)
- Detecting Height: 150mm
- Alarm Mode: Beep
- Belt Speed: (approx.) 30m/min
- Power Supply: Single-phase 220V, 50HZ
- Rated Output: (approx.) 225W
- Dimension: 1650(L)×1580(W)×1000(H)mm
- Weight: (approx.) 400kg
- The Oshima ON-688CDD6 is enhanced with a print function that other models do not have.
- The needle detector will trigger an alarm and reverse the conveyor automatically when a needle is detected.
- The ON-688CDD6 needle detector has an automatic calibration function every two hours of operation.
- The Oshima ON-688CD6 needle detector is equipped with an extended 10-point sensor probe that greatly improves sensitivity and reliability.
- The Oshima needle detector can be operated via the touch screen and supports three detection modes (high sensitivity, standard and fabric dyed), purposefully designed to meet different detection conditions together.
- Detection method: Magnetic induction
- Detectability: Fe ¢ 0.8mm
- Sensitivity adjustment: Low: 20 - 30 mm ; Height: 30-40mm
- Detection Area: 25 (W) × 50 (L) mm
- Alarm mode: whistle and light
- Detection mode: magnetic induction
- Detection capability: iron Φ0.8mm
- Width of detector: 600mm
- Height of detection: 120mm
- Sound signaling: Beep
- Conveyor speed: (approx.) 30m / min
- Power supply: 220V, 50Hz
- Power Consumption: 150W
- Dimensions: 1598 (L) x1040 (W) x903 (H) mm
- Weight: (about) 230kg
- Detection mode: magnetic induction
- Detection capability: iron Φ0.8mm
- Width of detector: 600mm
- Port height detection: 100mm
- Sound signaling: Beep
- Conveyor speed: (approx.) 30m / min
- Power supply: 220V, 50Hz
- Power Consumption: 110W
- Dimensions: 1650 (L) x1050 (W) x920 (H) mm
- Weight: (about) 250kg
- The Hashima HN-30 hand held needle detector has a small detection area, finding damaged needles or precise metal fragments.
- Two steps of sensitivity adjustment: Low and High for different clothes.
- Alarm mode: sirens and lights.
- Magnetic sensor has high sensitivity and long service life.
- The Hashima HN-30 needle detector is compact in size, easy to move
- Model: HN-880C-120 / 140 / 160 / 180
- Detecting ability: Fe 0.8mm(120mm) Fe1.0mm(140mm) Fe1.2mm(160mm) Fe1.5mm(180mm) sphere or above
- Detecting width: 600mm
- Detecting height: 120mm (standard) / 140mm / 160mm / 180mm
- Conveyor speed: 15 - 40 / minute
- Size: 1598 (L) × 1040 (W) × 903 (H) mm
- Weight: 230kg
The Easement HD-900E carton metal detector get Detecting Width: 870mm; Detecting Height: 460mm,carry Max.50KG. Mostly used to detect the whole case after packing, to find out the blade, scissors, such a little big metal items left inside. Adopt the most advanced magnetic detecting technology, use the latest computer control system, through sampling system to filter jamming signal, make the machine work more stable.
- The Easement HD-2650T dual-probe needle detector adopts the most advanced magnetic detection technology, uses the latest computer control system, Integrates two-head multifunction detection and can realize any detecting head can be operated independently.
- The Easement needle detector adopts magnetic circuit symmetry detection structure, reduces magnetic radiation, conforms to green environmental protection concept, magnetic closed-loop detection and detection channel, improves detection accuracy and Strong anti-magnetic interference, reducing the rate of misconception, to adapt to the harsh working environment.
- Detecting Mode: magnetic induction mode
- Detecting Capacity: iron ball Ф0.8mm
- Sensitivity Set: stepless
- Detecting Width: 600mm
- Detecting Height: 100mm
- Alarm mode: beep
- Conveyer Belt Speed: 30m/min
- Power Supply: Single-phase 220V,50Hz
- Power: 110W
- Dimensions: 1650(L)×1050(w)×900(H)mm
- Weight: 200kg
