- Water amount (level) automatic control: ±2L.
- Water temperature automatic control: ±1°C.
- Agitation speed automatic control: ±2spm.
- Spin speed: ±3rpm.
- Washing time: ±10seconds.
- Spin time: ±10seconds.
- Loading capacity: 10.5kg max.
- Language: English/Chinese.
- Door safe switch.
- LED indicators signals
- Temperature automatic control: ±1°C.
- Drying time: ±10seconds.
- Cooling time: ±10seconds.
- Loading capacity: 10.5kg max.
- Language: English/Chinese.
- Door safe switch.
- LED indicators signals
- 7” Touchscreen Operation, easy to use.
- Working Positions: 9 positions (or 3 positions for option)
- Abrasion Stoke Length: 24±0.5mm,60.5±0.5mm.
- Load Weight: 9kPa, 12kPa adding weights.
- The rotational frequency of the drive unit: outer driving unit,47.5±2.5rpm，Inner driving unit, 44.5±2.4rpm..
- Pressing Weight: 2.5±0.5kg.
- Pressing Weight Diameter: 120±10mm.
- Random tumble pilling tester RF3194N are designed to be traditional with four test chambers.
- Silent operation improves lab experience.
- Compressed air injection during test helps keeping specimen tumbling randomly to get more accurate testing result.
- Settings and operations are simplified. All operations can be accessed through touchscreen.
- LED lighting for easy observation of the specimens through the front viewing windows.
- Specimen rack rotation speed：40±2rpm
- Temperature range: Room Temp. to 97ºC
- Temperature accuracy: ± 0.5ºC
- Rate of temperature rise: Max. 2ºC/min
- Internal materials: Stainless Steel 316L
- Safety Device: Safety door switch, Over-temperature protector, Low water level protection.
- Automatic Water Inlet and Draining.
- 20 units of 550mL containers
- 20 units of 1200mL containers
- The Universal Tensile Tester RF-US5KL is designed to test a wide range of materials for tension, compression, flexure, shear and peel properties.
- Test scope: Knitted, Woven, nonwoven, leather, paper, etc.
- Core components such as loadcells, ball screws, and motors use high quality parts to ensure test accuracy and precsision.
- The Universal Tensile Tester RF-UD10KL is designed to test a wide range of materials for tension, compression, flexure, shear and peel properties.
- Crosshead can automatically move to different gauge length, no need of manual adjustment.
- Loadcells are automatic detected.
- The Universal Tensile Tester RF-US5K is designed to test a wide range of materials for tension, compression, flexure, shear and peel properties.
- Scope： Knitted, Woven, nonwoven, leather, paper, etc.
- Fixtures are embedded with chips containing information about the fixture. System can identify them and prevent mismatch of fixtures during use.
- Universal Tensile Tester RF-UD10K equipment three cameras are installed on the base platform and the crosshead. Two are used to monitor and detect speciment slippage at the clamp face. One is used for recording the test.
- Crosshead can automatically move to diferent gauge length, no need of manual adjustment.
- Cameras record the whole test procedure for future reference and reduces arguments.
- LaboDDD get used 7 inch touchscreen control.
- Bath water temperature automatic control:±0.5°C.
- Bath water temperature can be set.
- Low liquid level protection.
- Max. detergent capacity:5L/time.
- Liquid pump rate:10-1500mL/min.
- Pump accuracy:±0.5mL/min.
- Max. weighing capacity:100g.
- Weighing accuracy:± 0.01g.
- Dimension of stainless steel cylinder: 13inch (H), 8.75inch (Dia.),
- Capacity of Cylinder 7650mL.
- Rotation speed of cylinder: 45-50rpm (adjustable).
- Rotation axis angle of cylinder: 50º.
- RF6058 have rotating cylinder with electric control function.
- Cylinder with automatic lock function.
- Power Supply: AC230V 50Hz/60Hz.
Extracting position: Triple.
RF-F018C have extraction tube- 12mm (OD), 10 mm (ID).
Plunger Weight (including test weight): 1kg.
Power: 230V AC, 50HZ, 3.15A.
Overall Dimension: 500(L) × 120(W) ×380(H)mm.
Weight: Approximate 7kg.
Test cups moving speed：2rpm.
RF4319 test cup：8 units.
Power：AC 230V，50Hz/60Hz.
Dimension： 810(L)×410(W)×250(H)mm.
Weight：Approximate 17kg.
- Air Permeability Tester RF4308E included testing device, different size of test heads, vacuum pump and micro computer.
- Control the pressure difference between the two sides of the specimen accurately.
- Automatically calculate the air permeability index
- Touchscreen operation
- Testing ranges automatic selection.
- PC softwware for data collection and testing report output.
- Differential pressure testing function for mask testing is built in.
- Test Solution Apply：0.03-0.45ml selectable.
- Applicable test solution Accuracy: ± 0.003ml.
- RF4008 MMT: test time can be set
- Loading weight：1.0kg, 1.5kg, 2.0kg can choose.
- Improved test sensors for better conductivity and correlation test results.
- Dynamic water spread diagram is displayed.''Grading mode: GB, AATCC scoring method.
- Specimen Size：100mm x 100mm (Max. 120mm x 120mm)
- Sample Template: 100mm × 100mm ± 1mm
- RF4008MDT use Precision Camera
- LED Illumination
- PC Software
- Data Transfer：USB cable
- Test Report：Automatic saved and easy print
- Temperature Range 120～300℃
- Pressure 40±10gm/cm2 or 8.89 g/cm2 or 9 g/cm2
- Test Area 50mm x 110mm
- RF6116A have Touchscreen Control
- Power AC 230V，50Hz/60H
- Dimensions 240(L)×500(W)×220(H)mm
- Weight Approx. 13kg.
- Rotary extension device
- Specimen clip
- Specimen template
- RF3508 have loading weight: 3kg, 2 unit
- Scale ruler
- Overall dimension: 250(L)×500(W)×100(H)mm
- Weight: Approximate 20kg
- Crease Recovery Tester is used to test a fabric specimen which folded under a predetermined load in a preset of time then release, transfer the specimen to the recovery scale’s specimen holder. Record the crease recov-ery angle.
- Crease Recovery Tester RF3301 included folding stand, loading weight, crease recovery scale tester and specimen holder.
- The Fabric Drape Tester RF3305A is used to measure and calculate the coefficient of drape of a fabric specimen.
- The RF3305A uses a digital camera to capture the image of the drape.
- PC software calculate the coefficient of drape.
- PC software can display images and output report.
- The RF3305A is rotatable model, specimen rack can be rotated.
- Equipment stand can be leveled.
- Water container: Max depth 100mm.
- Crossbeam can be leveled.
- 12 pcs specimen clamps, can do FZ/T and AATCC tests simultaneously.
- RF4008WV equiped 6 pcs 165mm and 6 pcs 250mm stainless steel rulers, resolution is 1mm.
- 12pcs top specimen clamps for holding the specimens vertically.
- 12pcs bottom tension clamps ensure the specimens hanging vertically.
- Multi-selection of speed：20rpm, 25rpm, 30rpm, 40rpm, 50rpm, 60rpm, 70rpm
- Pilling or Snagging box：2 boxes
- Magnetic liner back plate for quick installation and changing
- Snagging Box：Optional
- M&S Pilling and Snagging Box: Optional
- BS8479 Octagonal Snagging Drum: Optional
- Sample Mounting Jig：Optional
- Power: AC230V 50Hz/60Hz
Electronic crockmeter RF3176 determines the color fas-tness of textiles to dry or wet rubbing. It includes counter, stainless steel clip, test finger (16mm diameter). Electronic crockmeter includes digital electronic pre-settable counter. It mo-torized for frequent use and long run tests. Max. stroke up to 9999 times. RF3176G Rubbing Colorfastness Tester is designed according to the JIS L 0849, Type Ⅱ Gakush-in_Type. Mainly used for color-fastness tester of colored fabrics.
